Hello new to the forum and its great.
I have a couple of quesions about the SUPER Quad bowtie antenna...probably got the name wrong...aslo sorry if this is the wrong place to address this, just didn't see a tab to post on the page I was looking at.
I want to make a version of the Walltenna and yours. My questions:
1. Is there a spcific dimension for the ground insulators? I.E. spacing between the whisker arrays and the reflector?
2. What determines the spacing between the tips of each individual V (2"-5")?
3. Lastly will 4 whiskers work verses 8. If so do the baulin contacts have to be centered between them or can I run leads to the bottom and connect there...as with the walltenna?
My thought is to use a framed canvas...use copper tape for the leads/whiskers, cover the reverse side with foil (against wall) for a reflector and then have the baulin at the bottom.
Thanks for the help and forum.
